LINSYS DC Series

1. Uniform, dot-free, smooth and comfortable luminary, with classy aluminum-plastic texture.
2. Support rigid split joint or soft jumper linking, up to 5 meters [16.4ft] run length in seamless connection without brightness difference.
3. Simple and quick assembly DIY concept, patented design.
4. Surface or flush mounting by magnet, magnet+metal sheet or bracket.
5. Multiple lengths, multiple CCT, high light efficiency for easy configuration.
6. Dimmable available with PWM signal.
7. 50,000h lifespan, 5 years warranty, CE, UL, RoHS approval.





Download Product Leaflet >
Category:

Description

Installation type Surface Mounted

Protection class IP 20

Dim-able built-in (optional) – Article number + DIM

Comes in Beam Angle of
FROSTED 120° Degrees

Lumens 2610~2830 lm

CRI 80 | 90 (optional)

Wattage 12 W
Protection class IP 20 · Safety class II
Cover frames and luminaire housings made of Plastic & Aluminum

Voltage 220/240 VAC

Environmental Temperature – -20℃ to 45℃

Environmental Humidity 0%~95%
LED colour temperature optionally 2700 K,5000 K & 6000 K

3000 K – Article number
4000 K – Article number
6000 K – Article number

Body Color White

Dimensions type L 100xW11XH11.8mm







.
